Co2 Type Fire Extinguisher

Fire Extinguisher

Safety shield deals with all type of fire extinguishers that are specially designed for high performance and to achieve rapid Fire knock down capability for protection of light, ordinary and high Hazards for all type of industries. Safety shield is one of the prominent quality and cost effective fire ABC extinguishers dealers in chennai. Safety shield offers best service, Annual maintenance Contract(AMC), upgrade for all type of extinguishers for all type of industries Safety shield is the most trusted co2 fire extinguisher dealers in chennai. Safety shield provides refilling services for all types of fire extinguishers

Product Overview

Carbon dioxide type fire extinguisher are suitable for B & C Class of fires involving all flammable liquids, gases, live & delicate, Machinery Fires, Electrical & sophisticated electronic equipments fires transformer & switch gear fire.

Enquire Now

Product Features


CO2 extinguishers are the perfect weapon against large, hard to fight Class B and C fires. CO2 extinguishers offer higher storage capacity than regular sized CO2 extinguishers.


Extinguishers coated with pure polyester powder coating for superior quality which is tested for higher impact resistivity and flexibility.

Easy Snap Lever Lock

Complete tamper proof safety seal with a simple squeezing mechanism with Easy snap Lever lock safety seal

Pressure Gauge

Easy to read Pressure gauges that helps you check the rediness of the extinguisher.

EPDM rubber hose

Superior grade EPDM Rubber braided hose is more flexible than the normal rubber used in hose pipe and also far less prone to cracks.

Smart Handling

Our portable extinguisher is very easy to handle during fire hazards

Maintenance & Service

Our high performance cost effective extinguishers are very easy to maintain, service and rechargeble


As per your needs, you can choose fire extinguishers from our wide ranges and capacitye

Technical Specification

Fire Extinguisher Capacity Throw of Jet Maintained At Least 90% Of Contests Range of Jet Empty.wt(Approx) Full wt. (Approx) Fire Rating Working Pressure Hydro Pressure Brusting Pressure
2 KG 8 sec 10 sec 2 mtr. 2.2 kg 8.2 kg 13 B 60 KGF/CM2 250 KGF/ CM2 600 KGF/ CM2
3 KG 8 sec 16 sec 3 mtr. 9.5 kg 12.5 kg 21 B 60 KGF/CM2 250 KGF/ CM2 600 KGF/ CM2
4.5 KG 8 sec 20 sec 3 mtr. 12.5 kg 17 kg 21 B 60 KGF/CM2 250 KGF/ CM2 600 KGF/ CM2
6.5 KG 10 sec 20 sec 4 mtr. 20 kg 26.5 kg NA 60 KGF/CM2 250 KGF/ CM2 600 KGF/ CM2
9 KG 15 sec 36 sec 4 mtr. 26 kg 35 kg NA 60 KGF/CM2 250 KGF/ CM2 600 KGF/ CM2
22 KG 20 sec 60 sec 4 mtr. 43.5 kg 66 kg NA 60 KGF/CM2 250 KGF/ CM2 600 KGF/ CM2

Suitable for classes

Class B

Class B fires are fires in flammable liquids such as gasoline, petroleum greases, tars, oils, oil-based paints, solvents, alcohols

Class C

Class C fires are fires involving energized electical equipment such as computers, servers, motors, transformers, and appliances..

Applicable Fire Areas

ABC Type fire extinguisher covers A, B, C class of fires which includes Papers, Wood, Cloth, Rubber, Plastic & inflammable liquid like oil, Petrol, Paints, Petrochemical Product, Resins, Gases in the compressed Form like Oxygen, Acetylenes, LPG & CNG, Electrical & Sophisticated electrical equipments.

Chemical Plant

Oil Ring


Electrical substation

Server Room

Construction sites



General Office Areas

We are ready to protect your environment from all fire hazards
